Sunrans 8M Acrylic Dual Zone Swim Spa Hot Tub Combo SR859

Graphic
Detail

Sunrans 8M Acrylic Dual Zone Swim Spa Hot Tub Combo SR859

swim spa endless pools swimming pools for sale

Size:
Product dimension:4000mmx2200mmx950/1400mm
Product dimension4100mmx2200mmx1400mm

swim spa endless pools swimming pools for sale

seat capacity: 6 Persons

Gross weight: 1650kg

Packing dimension:4100*2300*1500mm

Packing dimension 4200mmx2300mmx1500mm

Container load: 0pc/ 20GP; 1pc/ 40ft

Parameters

seat capacity: 6 Persons

Gross weight: 1650kg

Packing dimension:4100*2300*1500mm

Packing dimension 4200mmx2300mmx1500mm

Container load: 0pc/ 20GP; 1pc/ 40ft

SPA part	Swimming part
Seating Capacity:6 Persons	Seating Capacity:0 Persons
Lounge:4 Persons	Lounge:2 Persons
Dimensions/Weight/ Container load
Product dimension 4000mmx2200mmx950/1400mm	Product dimension 4100mmx2200mmx1400mm
Packing dimension 410023001500mm	Packing dimension 4200mmx2300mmx1500mm
Weight	1650KG
Water capacity	3300 US Gallon/ 12500Liters
Container load	0pc/ 20GP; 1pc/ 40ft
Shell
Shell colors	10 color available
Shell material	Aristech Acrylic
Pumps--SPA Part (UL,CE, KC approved)	Pumps--Pool Part (UL,CE, KC approved)
Jet pump 1: 3.0HP	Jet pump 1: 3.0HP
Jet pump 2: 2.0HP	Jet pump 2: 3.0HP
Jet pump 3: 2.0HP	Jet pump 3: 3.0HP
Jet pump 4: 2.0HP	Jet pump 4: 2.0HP
Jet pump 5: 2.0HP	Jet pump 5: 2.0HP
Circulation pump:1HP	Circulation pump:1HP
Air blower:1.5HP	Air blower: no
Electrics--SPA Part	Electrics--Swimming Part
Control system: America Balboa control	Control system: America Balboa control
Max power consumption: 13225Watt 20.1A in 380V 50Hz	Max power consumption: 13600Watt 20.6A in 380V 50Hz
Heater: 3KW/220-240VAC	Heater: 3KW/220-240VAC
Underwater lighting:5″ LED	Underwater lighting:5″ LED
Jet --SPA Part	Jet --Swimming Part
Jets total (pc):151	Jets total (pc):41
Massage jets (pc): 133	Massage jets (pc): 39
	Super size U shape swim jet with led (pc): 2
Air jets (pc): 18	Air jets (pc): 0
Filtration
Filter	Front access filters
Effective Filtration Area	100 sq. ft.
Ozone Generator	200mg/h
Features
Water diverter(pc): 6	Water diverter(pc): 4
Air regulater(pc): 2	Air regulater(pc): 6

Technical Specifications

Item	Specification
Product Dimensions	8100 × 2200 × 1400mm
Packing Dimensions	8200 × 2300 × 1500mm
Seating Layout	6 Seats + 4 Loungers
Shell Material	Acrylic, 12 colours available
Spa Jet Pumps	DXD-320E 2.0HP × 6 units
Swim Pumps	DXD-330A 3.0HP × 4 units
Circulation Pumps (Spa)	DXD-310A 1.0HP × 1 unit
Circulation Pump (Pool)	DXD-310A 1.0HP × 1 unit
Air Blower (Spa)	DXD-6X 1.5HP × 1 unit
Control System (Spa×2, Pool×1)	Babbitt GS523DZ + VL801D × 3 sets
Electronic Switches (Pool)	V-209H momentary × 2 sets
Heater (All Zones)	3KW / 220-240VAC
Underwater Lights	Large waterproof LED × 3 pcs
Total Jets	176 pcs
50mm SS Direct Jets	145 pcs (116 spa, 29 pool)
3' SS Direct Jets	12 pcs (8 spa, 4 pool)
3' SS Single Rotational Jets	10 pcs (7 spa, 3 pool)
5' SS Direct Jets	3 pcs (2 spa, 1 pool)
5' SS Single Rotational Jets	2 pcs (spa only)
5' SS American Direct Jets	2 pcs (pool only)
15' U-Shape Large Jets	2 pcs (pool only)
Filter Housings	Dual-canister (2 sets) + single (2 sets)
Filter Cartridges	Coarse thread × 4 pcs
Effective Filtration Area	100 sq. ft.
Ozone Generators	220V AC × 2 units (large)
Ozone Nozzles	Black × 4 pcs
Air Bubbler Nozzles	9-hole SS, 18 pcs (spa)
Water Diverters	2' transparent, 4 pcs; 1.5' cross (pool), 2 pcs
Air Regulators	1' cross, 4 pcs
Suction Inlets	N/A (listed as 22 return inlets)
Return Inlets	2' perforated SS, 22 pcs (11 each zone)
Overflow	1.5' strip SS (spa), 1 pc; 1' strip SS, 2 pcs
Waterfalls	Bar-shaped (carbon grey, no light), 2 pcs
Fountains	Small (8 pcs) + exhaust (2 pcs)
Headrest Pillows	KB251 (6 pcs) + KE1030 (1 pc)
Champagne Buckets	Large black, 2 pcs
Speakers	Large (4 pcs) + oval lift (2 pcs)
Support Frame	#304 Stainless Steel
Skirt Options	H03, H04, H06 PVC (with corner plates)
ABS Base	Black textured, 1 set
Optional LED Water Level Lights	47 pcs
Optional Insulation	Body/pipe/skirt available
Optional Cover	Standard or thick

Application Scenarios

Elite Athlete Home Training
Competitive swimmers preparing for triathlons or open-water events will appreciate the SR859's 8.1m length and four 3.0HP pumps. The current can be dialled up to mimic sprint paces, while the separate spa zone allows immediate post-session recovery.

Luxury Resort & Wellness Centre
Install the SR859 as a headline amenity. The triple-zone control lets guests choose between active swimming, gentle spa relaxation, or hydrotherapy. The 176 jets and extensive water features create a genuine spa atmosphere, attracting premium clientele.

Large Estate & Mansion Grounds
Homeowners with substantial properties can integrate the SR859 into a landscape design, perhaps alongside an outdoor kitchen and fire pit. The 47 optional LED lights and two champagne buckets turn evening soaks into social events.

Multi-Generational Family Compound
Grandparents can enjoy the warm spa zone while grandchildren use the swimming channel. The four loungers offer comfortable resting spots for those who prefer not to fully immerse. The 220cm width provides ample shoulder room.

Physiotherapy & Sports Medicine Facility
Clinics specialising in aquatic therapy can use the SR859 for group sessions. The consistent current supports gait training, while the spa zone serves individual patients. The 1.5HP air blower adds bubble massage for sensory therapy.

Installation & User Experience

Site Requirements
The SR859 needs a reinforced concrete slab of at least 8.4×2.5m with a load capacity exceeding 500kg/m². Access for a crane or low-loader is mandatory – the unit ships fully assembled. Allow 1.5m clearance on all sides for pump and filter access.

Electrical Installation
Three dedicated 220V/50Hz circuits are required (40A each). Each must have its own 30mA RCD. The control panels can be mounted remotely in a dry equipment room if desired. Use a licensed electrician familiar with multi-pump spa systems.

First Fill & Commissioning

Position the unit using a crane (dry weight approx. 1,100kg).
Level the ABS base and connect electrical feeds.
Fill all three zones slowly to prevent air locks.
Power on each VL801D panel sequentially and set zone temperatures.
Test swim current from low to high, checking for smooth acceleration.

Operational Best Practices

Clean the four coarse-thread filter cartridges weekly – the high bather load creates more debris.
Monitor pH daily; the 1.5HP air blower can raise pH if used excessively.
Use the electronic switches (V-209H) for quick current activation during workouts.
The champagne buckets are decorative; do not use them for hot beverages.

Winter & Extended Shutdown
If the SR859 will be unused for more than a month in freezing weather, drain all zones completely. The extensive plumbing network takes time to drain; use the bottom valves and compressed air to clear residual water. The optional insulation package is highly recommended for year-round operation.
