Size:6700mm×2200mm×1530mm
seat capacity: 2 Persons
Gross weight: 1050kg
Packing dimension: 6800mm×2300mm×1630mm
Container load: 2pc/20ft; 1pc/ 40ft
seat capacity: 2 Persons
Gross weight: 1050kg
Packing dimension: 6800mm×2300mm×1630mm
Container load: 2pc/20ft; 1pc/ 40ft
Seating | |
Seating Capacity | 2 Persons |
Lounge | N/A |
Dimensions/Weight/ Container load | |
Product dimension | 6700mm×2200mm×1530mm |
Packing dimension | 6800mm×2300mm×1630mm |
Weight - Dry/Filled | 1050KG/ 16050KG |
Water capacity | 3963 US Gallon/ 15000Liters |
Container load | 2pc/20ft; 1pc/ 40ft |
Shell | |
Shell colors | 5 color available |
Shell material | Aristech Acrylic |
Pumps (UL,CE, KC approved) | |
Swimming pump | 3.0HP×3pcs |
Jet pump | 2.0HP×1pc |
Fountain pump with separate electronic control | 0.53HP×1pc |
Circulation pump | 1HP×1pc |
Electrics | |
Control system | America Balboa control |
Max power consumption: | 12400W 18.8A in 380V/50Hz |
Heater (America Balboa brand) | 3KW/220-240VAC |
Underwater lighting | 5″ LED×2pcs |
Jet Configurations | |
Jets total (pc) | 44 |
U shape-Swim jets (pc) | 3 |
Massage jets 5" (pc) | 1 |
Massage jets 3.5" (pc) | 2 |
Massage jets 1" (pc) | 38 |
Filtration | |
Filter | Double Top-mount filters |
Effective Filtration Area | 100 sq. ft. |
Ozone Generator | 50mg/h |
Features | |
Fountains (pc) | 12 |
Water diverter 2" (pc) | 1 |
Air regulater(pc) | 1 |
Suctions (pc) | 6 |
Gate valves (pc) | 2 |
Drain valve (pc) | 1 |
Headrest pillows(pc) | 2 |
Support frame | #304 Stainless steel |
Overflow outlet (pc) | 1 |
Skirt: | Brown/ Grey / Black color |
